Specification | ||
Voltage (single) | 220~240V AC 50/60HZ | |
Motor Power | 18500W | |
Motor Ampere | 15A | 7.5A |
No-Load Speed | High speed 780 rpm
| Dia. 12(1/12”) ~35mm (1-3/8”) |
| Low speed 400 rpm | Dia. 36(1-7/16”) ~60mm (2-3/8”) |
Tool Adopter inner dia. | 19.05mm | |
Adjustable in height for Max. Stroke |
135mm | |
Coolant Supply | Via Tool Holder | |
Magnet Power consumption | 85W | |
Magnet Adhesion | 22540 N/2300 kgf | |
Magnet dimension | 210mm x 100mm x 64mm | |
| Drilling Capacity | |
MT3 with Annular Cutter | Out. Dia. | Plate thickness |
16-60mm | 6-50mm | |
MT3 with Drill Chuck | Jacobs Taper | Drill Chuck Max. Dia. |
JT6 | Max. Dia. 16mm | |
Twist Drill | Max. Dia. 25mm | |
Moss Straight Shank Twist Drill | Shank ½ Max. outer dia. | |
Specs | |||||
Voltage (single) | 220~240V AC 50/60HZ | ||||
Motor Power | 18500W | ||||
Motor Ampere | 15A | 7.5A | |||
No-Load Speed | High speed 780 rpm
| Dia. 12(1/12”) ~35mm (1-3/8”) | |||
| Low speed 400 rpm | Dia. 36(1-7/16”) ~60mm (2-3/8”) | |||
Tool Adopter inner dia. | 19.05mm | ||||
Adjustable in height for Max. Stroke |
135mm | ||||
Coolant Supply | Via Tool Holder | ||||
Magnet Power consumption | 85W | ||||
Magnet Adhesion | 22540 N/2300 kgf | ||||
Magnet dimension | 210mm x 100mm x 64mm | ||||
Drilling Capacity | |||||
MT3 with Annular Cutter | Out. Dia. | Plate thickness | |||
16-60mm | 6-50mm | ||||
MT3 with Drill Chuck | Jacobs Taper | Drill Chuck Max. Dia. | |||
JT6 | Max. Dia. 16mm | ||||
Twist Drill | Max. Dia. 25mm | ||||
Moss Straight Shank Twist Drill | Shank ½ Max. outer dia. | ||||
