Portable Magnetic Drilling and Tapping Machine 930H Manila

Portable Magnetic Drilling and Tapping Machine 930H











Product Features




  • Special design of tapping handle makes tapping operation easier, any time you need right direction rotating for tapping or reverse for withdrawing just push it downward or release, even tap on a high hardness steel, this machine can attain it's function perfectly.

  • All the drill sleeves and tap fixtures are rapid-adaptor, the most convenient for replacement.

  • With safety torsion fixture, the torsion forces of each fixture are adjusted to match what they need to protect taps from being broken while operating.

  • The speed rates of this machine are changeable while operating, and the satiety of gears are ensured.

  • The most suitable for machinery parts, fittings, press modules, other modules and work-pieces.

  • Working table is an electronic magnet it can attract and release work-piece quickly.




















































































Model



930H



Drill Capacity



1/4"~1-1/4"
6~32mm



Tapping Capacity



3/8"~1-1/8"
10~30mm



Power



220V
3-Phase



HP



2



R.P.M.



756 456
303 186
127 51



Freeding Stroke



100mm



Body Stroke



150mm



Distance of Spindle Endto Base Plate



1000mm



Distance of Spindle Endto Table Top



630mm



Diameter of Column



102mm



Diameter of Table



420mm



Base Working Area



600x360



Table Stroke



480mm



Height



1530mm



Torsion Fixture Standard Fitting



7



Drill Sleeve Standard Fitting



3



Fittings Weight



8kgs



Machine Weight



228kgs
