Portable Magnetic Drilling and Tapping Machine C-250H Manila

Portable Magnetic Drilling and Tapping Machine C-250H











Product Features




  • Working table is an electronic magnet, it can attract and release work-piece quickly.

  • With revolveable locating device, more precision and faster for replacement of cutters working at the same hole.

  • Could be installed with revolveable cutters table for fast replacement of cutters.

  • With Withdraw free and withdraw end function for tapping. Depends on different needs of different work-pieces, users could choose one for working.

  • The seat of drilling handless is adjustable is adjustable, users could adjust the angle of drilling handles for convenience of working.

  • Drill sleeves, tapping adaptors and borer holder are all with rapid adaptor, very convenient for replacement of cutters.

  • Tapping adaptors with torsion control, tap bits are protected from being twisted off.

  • With circuit protection of breaking for motor, once any wire of three phases power source is broken off, this unit could cut off current to motor to prevent motor from being burn out.

  • With Voltage indicator, users could know powercondition any time.




















































































Model



C-250H



Drill Capacity



1/8"~1"
3~25mm



Tapping Capacity



3/8"~7/8"
10~22mm



Power



220V
3-Phase



HP



1-1/4"



R.P.M.



705 405
100 58



Freeding Stroke



100mm



Body Stroke



100mm



Distance Of Spindle Endto Base Plate



725mm



Distance Of Spindle EndtoTable Top



450mm



Diameter Of Column



80mm



Diameter Of Table



330mm



Bsae Working Area



440x300mm



Table Stroke



380mm



Height



1075mm



Torsion Fixture Standard Fitting



6



Drill Sleeve Standard Fitting



3



Fittings Weight



8kgs



Machine Weight



109kgs
