FREE STANDING HEIGHT (M)
25.6 HEIGHT UNDER HOOK (M)
76.6 JIB LENGTH (M) 30
MAX. LOAD (TON) 9
TIP LOAD (TON) 5.35T @30m Jib Length
COUNTER JIB LENGTH (M) 7.0 (Counter weight shall made by user according to Zoomlion drawings)
FIXING ANGLES included
WALLING FRAME / ANCHORAGES 5 set(s)
BASIC MAST L46G20
MAST SECTION L46A1 (1.6m*1.6m*3m)
HOISTING MECHANISM H37FP20-610P (37kw, inverter type, 0～100m/min)
SLEWING MECHANISM HPW55F1.130B HPW55F2.130B (2×5.5kw, inverter type, 0～0.79r/min)
LUFFING MECHANISM L30FP35 (30kw, inverter type, min 15~85°)
POWER SUPPLY 440V/60HZ
CABLE EXTENSION 76.6m power cable
INCLUDED MASTS L46G20+L46A1×23
HOISTING ROPE 300m
INTELLIGENT MONITOR Load Moment Indicator, Anemometer etc. multifunction monitor
Each Tower Crane comes with following items:
1 set of jacking system including telescoping cage, hydraulic pump, cylinder
1 set of cabin, with AC
1 set of counter jib Full set of ladder and platform
Full set of electric control system
Full set of standard accessories
Full set of manuals
