Model -LG25
Power type Battery Rated capacity (Kg)- 2500
Load centre (mm)- 500 STD
Max.lifting height (mm) -3000
Free lifting height (mm)- 160 L5*W*T
Fork size (mm) -1070×120×40
Mast tilt angle (deg) -6/12
Front overhang (mm)- 460
Overall dimension
Overall length(with fork)(mm)- 3430
Overall width (mm)- 1150
Mast lowered height (mm) -2012
Overhead guard height (mm) -2210
Min.turning radius (mm) -2150
Min.intersecting aisle (mm)- Speed(load/unload)
Max.traveling speed (km/h)（F/R）- 10/12
Max.lifting speed (mm/s)（load/unload）- 260/420
Max.gradient (load/unload)(%) -12/15
Dead weight (kg)- 4150 S/P
Tread（front/rear）(mm) -950/930
Axle distance (mm)- 1500
Min.ground clearance
Mast (mm)- 135
Tire Front- 7.00-12-12PR
Rear- 18×7-8-14PR
Motor Travel(AC)(kW) -11
Lift(AC)(kW) -11
Battery(V/Ah)- 48/620
Working pressure(Mpa)- 16
Controller -ZAPI
Call/Text at +639772190370 +639426526646 look for Kenneth
