The hydraulic top hammer drill rig is able to work under extreme environments, with a working temperature range from -40℃ to 40℃. It’s most often used for drilling and breaking in fields and places like, mines, fire-fighting, geological exploration, road construction, rock collecting, national defense, to name a few. Rock drilling machine provided by our company is widely applied for the drilling and cutting of a wide range of rocks, such as marbles, granites, sandstones and limestones. This machine possesses these following advantages:
Feature:
1. A fast drilling speed significantly enhances the working efficiency.
2. A special structure guarantees the drilling precision, avoids material waste and saves construction cost.
3. This drilling machine also shows high stability and interference resistance.
4. A dust collecting system provides a clean and eco-friendly working environment.
2. A special structure guarantees the drilling precision, avoids material waste and saves construction cost.
3. This drilling machine also shows high stability and interference resistance.
4. A dust collecting system provides a clean and eco-friendly working environment.
Main specifications:
| JINGGONG Rock Drilling Machine | |
|---|---|
| Brand Name | JINGGONG |
| Origin | Fujian, China |
| Moving Style | steel crawler |
| Certificate | ISO 9001:2008 |
| Rated Power | 50KW |
| Rated Speed | 2300r/min |
| Applicable Strata | Marble/Granite/Sandstone/Limestone |
| Drilling Working Situation | Drilling&Cutting/Trimming The Step /Trimming The Whole Stone |
| Drilling Mode | Top Hammer Shock |
| Drilling Diameter | φ28mm-φ45mm |
| Drilling Depth | 1800mm |
| Drilling Frame Overall Length | 2500mm |
| Drilling Frame Stroke | 1800mm |
| Guide Rail overall Length | 2500mm |
| Guide Rail Stroke | 1800mm |
| Walking speed(High speed/low speed) | 4.5/2.5km/h |
| Grade Climbing ability | 30° |
Working scene:
Tips: The chromatic aberration is exist because I have reduced the quality of the picture for getting faster loadding speed on the internet.
