Product Description
MODEL SWDM220
Max. drilling diameter---- 2000
Max. drilling depth m---- 69/54
Engine power kw---- 242
Max. torque kN.m----- 245
Rotation speed rpm--------- 6~28
High-speed throwing soil (optional)-----70
Working weight t----- 76
Working height mm---- 22275
Main Parameters
MODEL: SWDM280
Working condition -----10.3 x 4.5 x 24.27 (m)
Transportation condition -----17.7 x 3.0 x 3.38 (m)
Total weight -----78T
Max. drilling diameter:with casing / without casing---- 1800 / 2500 (mm)
Max.drilling depth -----86(6 element) / 69(5 element) (m)
Min. working radius -----4240mm
Engine Model Cummins ------QSM11-335
Engine rated power -----250kw / 2100rpm
Engine maximum torque ----1704N.m / 1400rpm
Hydraulic System
Max. working pressure:main pump / auxiliary pump---- 28 / 28 (Mpa)
Max. oil flow rate:main pump / auxiliary pump ----520 / 140 (L/min)
