ENGINE PARAMETERS
Engine Model: YC4FA115-40
Rated Power : 114/3200 kw/rpm
Maximum Torgue: 300/1600-2400 Nm/rpm
Features: 4-cylinder in-line,4.214 liter
FRAME
Material: High tensile steel
Section: 170x60x5mm
Frame width: 800mm
BREAKING SYSTEM
Type Air brake system
Service brake: Dual-circuit air brake
Parking brake: Spring energy,Compressed air
operating on rear wheels
Auxiliary brake: Exhaust valve braking EVB)
GEARBOX WLY6T50c 6speed manual control
WHEEL TYRES Tyres: 7.00R16
FUEL TANK CAPACITY 120 Liters (iron)
VEHICLE DIMENTION(mm)
Wheel base: 3360
Maximum Gradeability: 20-25%
Chassis length: 5982
Cargo body size: 4m3
Maximum Driving Speed: 100 km/h
Overall Dimention: 600*2200*2750
WEIGHT(kg)
Kerb.Mass: 3840
Gross Vehicle Weight : 5500
Front axle loading capacity: 2000
Rear axle loading capacity: 3500
SUSPENSION
Steer AxeL: Semi-elliptical leaf spring with shock
absorbers and stabilizer
Drive Axel: Semi-elliptical leaf spring
ELECTRICAL SYSTEM
Type: SINOTRUK bus System with VCO
instrument
Voltage: 24V
Batteries: 2x12V,105Ah
Alternator: 28V/55A
Starter: 5kw
STEERING GEAR
Type: GY85-Hydraulically assisted
CLUTCH 300Adiaphragm spring clutch,
single plate
*100% Brand New
*With strong and reliable after sales support
*Spare Parts available
*Free Financing Assistant thru Metro bank Orix
*You can view the unit every Monday-Saturday
*Avail thru cash and bank financing (METROBANK ORIX Recommended)
*We are PHILGEPS PLATINUM MEMBER and LGU Supplier.
For your inquiries and quotations, kindly text or call the number provided below:
09953732991 (Globe/TM) 09237358109 (Smart/TNT/Sun)
look for Ms.Andrea S. Pajanel
